Here is the angle of the dangle formulas for calculating the change in sway bar stiffness.  First of all there are only 2 ways to change the stiffness of a bar.  The first is to change the bar size.  For that change you would use the formula below.

If you're substituting a larger diameter bar that otherwise has the same dimensions, the rate increase is simply:

(new diameter/old diameter) to fourth power

So when you change your bar from 18mm to 19mm, the stiffness increased 24%. (19/18)^4 = 1.24

Now, if you want to calculate the actual rate or have adjustable sway bars (several adjustment holes to change length of lever arm) and want to figure out the rate increase, you'll need to measure the bar and use a formula (from Fred Puhn's "How to Make Your Car Handle").

Formula for sway bar stiffness of a solid steel bar

500,000 D^4
K (lbs/in) = -------------------------------------

(0.4244 x A^2 x B) + (0.2264 x C^3)

B
----------------
A|  /                      \ C
| /                         \

A - Length of end perpendicular to B (torque arm - inches)

B - Length of center section (inches)

C - Length of end (inches)

D - Diameter bar (inches)

On a bar where the bars have nearly a 90 degree angle between the arms and center section, A = C for the calculations.

B
:----------------:
A  :                   : C (= A)
:                   :

Example calculation for a 25mm front bar D = 25mm = 0.984 inch

A = 11.25 inch
B = 31.5  inch
C= 11.25 inch

500,00 x 0.984^4
K = ------------------------------------------------ = 233 lb/in

((0.4244 x 11.25^2 x 31.5) + (0.2264 x 11.25^3))

Now for the second way to change the bar rate is to lengthen or shorten the “A” measurement, which is the Length of end perpendicular to B (torque arm - inches)

As you know the sway bar ends move up and down in an arch motion.  Raising and lowering the bar will effectively change the torque arm – inches, which is the “a” measurement in the formula.  Changing the torque arm – inches will either change the rate softer or harder. Changing the drop link length makes this change.  To find the rate change you would measure the “A” Length of end perpendicular to B (torque arm - inches) with the original setting and calculate the rate.  You would then make the change and re-measure Length of end perpendicular to B (torque arm - inches) and calculate the rate.  By dividing the new rate into the original rate you can determine the change in percent.

Now to the answer, 6mm is equal to .236”.  The effect on the torque arm – inches by lowering the sway mar will be less than .1”.  In the final analysis, the effect of 6mm is so small that it would be hart to even measure.
